PRY EV

EV Charge Point Power and Data Cable: PRY EV for Smart Charging

PRY EV is a combined EV charge point power and data cable designed for EV charging installations. It enables power delivery and communication between the consumer unit and EV charger within a single cable, helping simplify installation, support smart charging functionality and provide a reliable, future-ready solution for residential and commercial EV charging infrastructure. As a Prysmian EV cable solution, it serves as both an electric car charging cable and data link.

PRY EV is the Prysmian solution for dedicated power and data solution for modern EV charge points. Bringing together robust power cores and a four pair screened data cable, it provides power and data connectivity in a single cable allowing for faster, easier and safer installation. The hard-wired connection offers a more reliable and secure solution to Wi-Fi networks and improves the performance of smart EV charging outlets.

What is PRY EV?

PRY EV integrates four pair screened data cable with power cores, allowing one cable to supply the charger and the data link to upstream equipment or networks. In typical layouts it runs from the consumer unit, or distribution board, directly to the charging unit, reducing routes, terminations and penetrations. It functions as an EV charging cable and an EV data cable in one, reducing interfaces often required by separate power and data links.

  • Provides the power and connectivity required for smart functions such as load management, charger connectivity and remote monitoring.
  • Suited to new builds and retrofits where neat, compliant installations and minimal disruption are priorities.
  • Suitable for single-phase and three-phase supplies in domestic, commercial and light industrial settings where different conductor sizes may be required.

Why Combine Power and Data for EV Charging

Smart EV charging systems rely on reliable power and communications for functions such as load management, current monitoring, charging schedules and remote monitoring. By combining power and data connectivity within a single cable from the consumer unit to the EV charge point, PRY EV helps reduce installation complexity by removing the need for separate power and data cables which can simplify installation, and support a neat, professional finish. The integrated screened data cable also provides a secure hard-wired communications pathway between the consumer unit and charge point, reducing reliance on wireless connections and supporting smart charging functionality where required.

PRY EV's electromagnetic compatibility is supported through it's screened, twisted data pair, controlled lay-up and separation layers that maintain signal integrity alongside energised conductors. Correct screen termination, in accordance with installation requirements, helps preserve EMC performance in electrically noisy environments and supports dependable operation of the Prysmian EV cable. In short, an integrated EV charging cable with data improves reliability and reduces faults while enabling accurate metering and responsive load control.

Designed for Modern EV Charging Installations

PRY EV is designed to provide both power and data connectivity between a consumer unit and a fixed EV charge point. Combining three copper power cores with a complete four-pair screened data cable within a single sheath, it provides a practical solution where power delivery and communications are required in a single cable. The screened and twisted data cable supports reliable data transmission and can be used for data connectivity or current monitoring signals, helping support smart EV charging installations while reducing the need for separate power and data cable runs.

PRY EV is available in armoured and unarmoured constructions and has been designed specifically for EV charge point connections. The cable is tested to relevant performance standards and incorporates flame-retardant properties in accordance with BS EN 60332-1-2. Its hybrid construction supports consistent performance while simplifying installation through a single power and data solution.

Looking for a practical example? Watch how OM Electrical uses PRY EV on site and discusses the benefits of an integrated power and data cable solution.

PRY EV installation

Technical specifications and compliance

Construction
Three copper power conductors combined with a complete four-pair screened data cable within a single outer sheath. Available in armoured and unarmoured constructions.
Electrical
PRY EV is suitable for conductor operating temperatures of up to 90°C. Where the equipment allows for such operating temperatures, reference shall be made to Table 4E2A for unarmoured and 4E4A for armoured cables. Where it is known that the equipment is limited to 70°C operation, reference shall be made to Table 4D2A for unarmoured and 4D4A for armoured cable.
EMC
Screened, twisted pair supports reduced crosstalk in electrically noisy environments.
Standards
Flame retardant in accordance with BS EN 60332-1-2. The cable is designed and manufactured specifically for EV charge point power and data connections and is tested to support reliable performance in EV charging applications.

PRY EV - Frequently Asked Questions

The integrated screened data cable provides data connectivity and current monitoring signals between the consumer unit and EV charge point. It can be used for data connectivity or Current Transformer (CT) monitoring signals. Its screened construction provides a reliable hard-wired connection for modern EV charging installations.

A Current Transformer (CT) is used to monitor electrical current within an installation. The integrated data cable in PRY EV can be used to carry CT monitoring signals between the consumer unit and EV charge point where required.

Yes. PRY EV is available in both armoured and unarmoured constructions, allowing installers to select the most appropriate option for the installation environment.

PRY EV helps reduce installation complexity by combining power and data connectivity within a single cable. This means a single reel, one set of fixings, less drilling, less packaging and reduced waste on site. The integrated screened data cable can be used for data connectivity or Current Transformer (CT) monitoring signals, while the secure hard-wired connection helps avoid the risks associated with Wi-Fi and can improve smart EV charger performance. The F/UTP data cable also provides a future-ready solution for evolving EV charging technologies.
